CAT PUMP

柱塞泵

Direct Drive, Electric Motor

Brass

Model Number	Maximum Flow		Maximum Pressure		RPM	Drive Type*
Model Number	gpm	lpm	psi	bar	RPM	Drive Type*
1CX013R	0.13	0.5	1,000	69	1725	HS
1CX025R	0.25	1	1,000	69	1725	HS
4DX03ELR	0.3	1.1	2,000	138	1725	HS
1CX050R	0.5	1.9	1,000	69	1725	HS
2SF10ES	1	3.8	2,000	138	3450	HS
4DX10ER	1	3.8	2,000	138	3450	HS
4DX15ER	1.5	5.7	2,000	138	3450	HS
2SF20ES	2	7.6	2,000	138	3450	HS
4DX20ER	2	7.6	2,000	138	3450	HS
4SP21ELR	2.1	7.9	2,000	138	1750	HS
2SF22ELS	2.2	8.4	2,000	138	1725	HS
2SF22ES	2.2	8.4	2,000	138	3450	HS
3CP1130	2.4	9.1	2,200	152	1725	CC
5CP3105CSS	2.5	9.5	3,500	241	1725	CC
4DX27ER	2.7	10.3	2,000	138	3450	HS
740	2.8	10.6	5,000	345	1700	CC
2SF29ELS	2.9	10.8	1,500	103	1725	HS
2SF30ES	3	11.4	1,500	103	3450	HS
4DX30ER	3	11.4	2,000	138	3450	HS
2SF30GES	3	11.4	2,000	138	3450	HS
4SF32ELS	3.2	12.2	3,500	241	1725	HS
2SF35ES	3.5	13.3	1,500	103	3450	HS
2SF35GES	3.5	13.3	2,000	138	3450	HS
3CP1140	3.6	13.7	2,200	152	1725	CC
5CP3110CSS	3.6	13.7	3,500	241	1725	CC
340	4	15.2	1,800	124	1725	CC
5CP2140WCS	4	15.2	2,500	172	1725	CC
4SF40ELS	4	15.2	3,500	241	1725	HS
3CP1120	4.2	16	2,200	152	1725	CC
5CP3160CSS	4.3	16.3	3,500	241	1725	CC
4SF45ELS	4.5	17.1	3,000	207	1725	HS
5CP4120CSS	4.5	17.1	4,000	276	1725	CC
60	4.7	17.9	4,000	276	1725	CC
700	4.7	17.9	5,000	345	1750	CC
5CP3120	4.8	18.2	3,000	207	1725	CC
350	5	19	1,500	103	1725	CC
5CP2150W	5	19	2,000	138	1725	CC
4SF50ELS	5	19	3,000	207	1725	HS
5CP5120	6	22.8	2,500	172	1725	CC
5CP6120	7.4	28.1	1,200	83	1725	CC
56	8	30.4	2,500	172	1760	CC
5CP6190	10	38	1,200	83	1800	CC
7CP6110	10.5	39.9	2,000	138	1725	CC
*HS-Hollow Shaft, CC-Close Coupled

Nickel Aluminum Bronze

Model Number	Maximum Flow		Maximum Pressure		RPM	Drive Type*
Model Number	gpm	lpm	psi	bar	RPM	Drive Type*
237	2.3	8.7	1,500	103	1725	CC
247	3.6	13.7	1,200	83	1725	CC
347	4	15.2	1,800	124	1725	CC
357	5	19	1,500	103	1725	CC
*HS-Hollow Shaft, CC-Close Coupled

316 Stainless Steel

Model Number	Maximum Flow		Maximum Pressure		RPM	Drive Type*
Model Number	gpm	lpm	psi	bar	RPM	Drive Type*
2SF05SEEL	0.5	1.9	1,200	83	1725	HS
2SF10SEEL	1	3.8	1,200	83	1725	HS
2SF15SEEL	1.5	5.7	1,200	83	1725	HS
2SF22SEEL	2.2	8.4	1,200	83	1725	HS
3CP1231	2.3	8.7	2,000	138	1725	CC
2SF25SEEL	2.5	9.5	1,200	83	1725	HS
784	2.8	10.6	5,000	345	1700	CC
2SF29SEEL	2.9	10.8	1,200	83	1725	HS
2SF35SEEL	3.5	13.3	1,200	83	1725	HS
3CP1241	3.6	13.7	2,000	138	1725	CC
341	4	15.2	1,800	124	1725	CC
5CP6241CS	4	15.2	2,000	138	1725	CC
2SF42SEEL	4.2	16	1,000	69	1725	HS
3CP1221	4.2	16	2,000	138	1725	CC
781	4.7	17.8	5,000	345	1750	CC
351	5	19	1,500	103	1725	CC
5CP6251	5	19	2,000	138	1725	CC
5CP6221	7.4	28	1,200	83	1725	CC
7CP6111	10.5	39.9	2,000	138	1725	CC
*HS-Hollow Shaft, CC-Close Coupled

Direct Drive, Gas Engine

Brass

Model Number	Maximum Flow		Maximum Pressure		Engine RPM	Shaft
Model Number	gpm	lpm	psi	bar	Engine RPM	Shaft
4DNX25GSI	2.5	9.5	3,000	207	3450	3/4"
4DNX27GSI	2.7	10.3	3,000	207	3450	3/4"
740G1	2.8	10.6	5,000	345	3465	1"
3DX29GSI	2.9	11	2,500	172	3450	3/4"
2SF30GS	3	11.4	2,000	138	3450	3/4"
2SFX30GZ	3	11.4	2,500	172	3450	3/4"
66DX30G1I	3	11.4	4,000	276	3450	1"
4SPX32G1I	3.2	12.2	3,000	207	3450	1"
2SF35GS	3.5	13.3	2,000	138	3450	3/4"
4SF35GS1	3.5	13.3	3,500	241	3200	1"
3CP1120G	3.5	13.3	2,200	152	3600	3/4"
66DX35G1I	3.5	13.3	4,000	276	3450	1"
5CP3160CSSG1	4	15.2	3,500	241	3320	1"
66DX40G1I	4	15.2	4,000	276	3450	1"
4SF40GS1	4	15.2	3,500	241	3200	1"
60G1	4.2	16	4,000	276	3200	1"
4SF45GS1	4.5	17.1	3,000	207	3200	1"
5CP3120CSSG1	4.5	17.1	3,500	241	3353	1"
45G1	4.5	17.1	3,500	241	3353	1"
700G1	4.5	17.1	5,000	345	3465	1"
4SF50GS1	5	19	3,000	207	3450	1"
5CP5135CSSG1	5	19	3,500	241	3090	1"
5CP5140CSSG1	5.5	20.9	3,500	241	3060	1"
5CP6120CSSG1	6.7	25.5	1,600	110	3200	1"
56G1	8	30.4	2,500	172	3600	1"
5CP6190G1	8.7	33.1	1,200	83	3200	1"
7CP6110G1	10	38	2,000	138	3400	1"
7CP6170G1	12	45.4	1,800	124	3264	1"

316 Stainless Steel

Model Number	Maximum Flow		Maximum Pressure		Engine RPM	Shaft
Model Number	gpm	lpm	psi	bar	Engine RPM	Shaft
3CP1241G	3	11.4	2,000	138	3600	3/4"
3CP1211G	3.8	14.4	1,500	103	3400	3/4"
341G1	4	15.2	2,000	138	3515	1"
781G1	4.5	17.1	5,000	345	3465	1"
351G1	5	19	1,500	103	3515	1"
7CP6111G1	10	38	2,000	138	3400	1"

Solid Shaft
Solid Shaft
Brass

Model Number	Maximum Flow		Maximum Pressure		RPM	HP
Model Number	gpm	lpm	psi	bar	RPM	HP
3CP1130	2.4	9.1	2,200	152	1725	3.6
5CP3105CSS	2.5	9.5	3,500	241	1725	6
740	2.8	10.6	5,000	345	1700	9.6
1810	3	11.4	10,000	690	1500	20.5
3CP1140	3.6	13.7	2,200	152	1725	5.4
5CP3110CSS	3.6	13.7	3,500	241	1725	8.6
340	4	15.2	1,800	124	1725	4.9
310	4	15.2	2,200	152	950	6
5CP2120W	4	15.2	2,500	172	950	6.8
5CP2140WCS	4	15.2	2,500	172	1725	6.8
3CP1120	4.2	16	2,200	152	1725	6.3
5CP3160CSS	4.3	16.3	3,500	241	1725	10.3
45	4.5	17.1	3,500	241	1645	10.8
5CP3120	4.5	17.1	3,500	241	1645	10.8
57	4.5	17.1	4,000	276	1285	12.3
5CP4120CSS	4.5	17.1	4,000	276	1725	12.3
700	4.5	17.1	5,000	345	1700	15.4
60	4.7	17.9	4,000	276	1725	12.9
700	4.7	17.9	5,000	345	1725	16.1
5CP3120	4.8	18.2	3,000	207	1725	9.9
310	5	19	1,500	103	1190	5.1
350	5	19	1,500	103	1725	5.1
5CP2150W	5	19	2,000	138	1725	6.8
530	5	19	2,500	172	1100	8.6
5CP5120	5	19	3,000	207	1415	10.3
550	5	19	3,000	207	1415	10.3
56	5.5	20.9	3,500	241	1210	13.2
5CP5140CSS	5.5	20.9	3,500	241	1500	13.2
5CP6120	6	22.8	1,600	110	1450	6.6
5CP5120	6	22.8	2,500	172	1725	10.3
1570	6	22.8	6,000	414	1350	24.7
650	7	26.6	3,000	207	1000	14.4
5CP6120	7.4	27.1	1,200	83	1725	6.1
5CP6190	8	30.4	1,450	100	1450	7.9
56	8	30.4	2,500	172	1760	13.7
1560	8	30.4	4,000	276	1140	21.9
5CP6190	10	38	1,200	83	1800	8.2
1050	10	38	2,200	152	958	15.1
660	10	38	3,000	207	1429	20.5
3550	10	38	6,000	414	940	41.1
6810	10	38	10,000	690	600	68.5
7CP6110	10.5	39.9	2,000	138	1725	14.4
7CP6170	11	41.6	2,000	138	1450	15.1
1050	12	45.4	1,800	124	1150	14.8
7CP6170	12	45.4	1,800	124	1600	14.8
1580	12	45.4	3,000	207	1180	24.7
1530	15.6	59.3	1,500	103	1450	16
1540E	18	68.4	1,200	83	1,100	14.8
2510	20	76	2,000	138	1450	27.4
3560	20	76	4,000	276	1160	54.8
2530	21	79.8	1,200	83	860	17.3
3520	23	87.4	2,000	138	800	31.5
2530	25	95	1,000	69	1025	17.1
3560	25	95	3,000	207	1450	51.4
3535	36	136	1,200	83	800	29.6
6835	40	152	3,000	207	625	82.2
3545	45	171	1,000	69	765	30.8
6760	60	228	1,200	83	520	49.3
6775	75	285	1,200	83	650	61.6


Nickel Aluminum Bronze

Model Number	Maximum Flow		Maximum Pressure		RPM	HP
Model Number	gpm	lpm	psi	bar	RPM	HP
237	2.3	8.7	1,500	103	1725	2.4
277	3.5	13.3	1,500	103	1420	3.6
247	3.6	13.7	1,200	83	1725	3
347	4	15.2	1,800	124	1725	4.9
317	4	15.2	2,200	152	950	6
277	4.2	16	1,000	69	1725	2.9
357	5	19	1,500	103	1725	5.1
1057	10	38	2,200	152	958	15.1
3507	10	38	2,200	152	958	15.1
1057	12	45.4	1,800	124	1150	14.8
3517	14	53.2	3,000	207	800	28.8
2537	21	79.8	1,200	83	860	17.3
3527	23	87.4	2,000	138	800	31.5
3537	36	136	1,200	83	800	29.6
6747	48	182.4	2,000	138	615	65.8
6767	60	228	1,200	83	520	49.3
6777	75	285	1,200	83	650	61.6


316 Stainless Steel

Model Number	Maximum Flow		Maximum Pressure		RPM	HP
Model Number	gpm	lpm	psi	bar	RPM	HP
3CP1231	2.3	8.7	2,000	138	1725	3.2
784	2.8	10.6	5,000	345	1700	9.6
3CP1241	3.6	13.7	2,000	138	1725	4.9
5CP6241CS	4	15.2	2,000	138	1725	5.5
311	4	15.2	2,200	152	950	6
3CP1221	4.2	16	2,000	138	1725	5.8
781	4.5	17.1	5,000	345	1700	15.4
781	4.7	17.9	5,000	345	1750	16.1
5CP6251	5	19	2,000	138	1725	6.8
5CP6221	6	22.8	2,000	138	1400	8.2
5CP6221	7.4	28	1,200	83	1725	6.1
1051	10	38	2,200	152	958	15.1
1861	10	38	3,000	207	1429	20.5
3801	10	38	5,000	345	915	34.2
7CP6111	10.5	39.9	2,000	138	1725	14.4
7CP6171	10.5	39.9	2,000	138	1450	14.4
1051	12	45.4	1,800	124	1150	14.8
3811	14	53.2	3,000	207	800	28.8
6811	15	57	5,000	345	600	51.4
6801	15	57	7,000	483	600	71.9
1531	15.6	59.3	1,500	103	1450	16
1541	18	68.4	1,200	83	1,100	14.8
2511	20	76	1,500	103	1450	20.5
2531	21	79.8	1,200	83	860	17.3
2831	21	79.8	1,200	83	860	17.3
3521	23	87.4	2,000	138	800	31.5
3821	23	87.4	2,000	138	800	31.5
2531	25	95	1,000	69	1025	17.1
6821	25	95	3,000	207	615	51.4
3531	36	136	1,200	83	800	29.6
3831	36	136	1,200	83	800	29.6
6831	40	152	2,300	159	625	63
3541	45	171	1,000	69	765	30.8
3841	45	171	1,000	69	765	30.8
6841	48	182.4	2,000	138	615	65.8
6761	60	228	1,200	83	520	49.3
6861	60	228	1,200	83	520	49.3
6771	75	285	1,200	83	650	61.6


Duplex Stainless Steel

Model Number	Maximum Flow		Maximum Pressure		RPM	HP
Model Number	gpm	lpm	psi	bar	RPM	HP
1051D	10	38	2,200	152	958	15.1
661D	10	38	3,000	207	1429	20.5
3501	10	38	5,000	345	915	34.2
1051D	12	45.6	1,800	124	1150	14.8
3511	14	53.2	3,000	207	800	28.8
3822	23	87.4	2,000	138	800	31.5
3832	36	136	1,200	83	800	29.6
6762	60	228	1,200	83	520	49.3
6862	60	228	1,200	83	520	49.3

活塞泵

Solid Shaft

Brass

Model Number	Maximum Flow		Maximum Pressure		RPM	HP
Model Number	gpm	lpm	psi	bar	RPM	HP
280	3	11.4	1,000	69	1330	2.1
290	3.5	13.3	1,200	83	1200	2.9
333	4	15.2	1,200	83	1070	3.3
430	5	19	1,000	69	1040	3.4
323	5	19	1,500	103	1000	5.1
623	6	22.8	1,200	83	850	4.9
820	10	38	1,000	69	940	6.8
390	12	45.6	600	41	1200	4.9
1010	13	49.4	700	48	900	6.2
2520	25	95	800	55	772	13.7
6040	40	152	1,500	103	500	41.1
6020	60	228	1,000	69	500	41.1

316 Stainless Steel

Model Number	Maximum Flow		Maximum Pressure		RPM	HP
Model Number	gpm	lpm	psi	bar	RPM	HP
281	3	11.4	1,000	69	1330	2.1
291	3.5	13.3	1,200	83	1,200	2.9
331	4	15.2	1,200	82	1070	3.3
431	5	19	1,000	69	1040	3.4
621	6	22.8	1,200	83	850	4.9
821	10	38	1,000	69	940	6.8
1011	13	49.4	700	48	900	6.2
6041	40	152	1,500	103	500	41.1
6021	60	228	1,000	69	500	41.1
